Jaws Crusher
Laboratory jaw crushers allow you to process hard materials in extremely small sizes. In this sense, the laboratory type jaw crusher allows product output between 0 and 5 mm. You can also achieve higher product output by adjusting the grain size.
The laboratory jaw crusher is built to create a high user experience. In this direction, uninterrupted spare parts support of the device, which has an extremely ergonomic structure, can also be provided by us. At this point, the device has an extremely durable and highly resistant structure with its reinforced steel construction body and all its components.
The size of the material to be crushed can be adjusted by means of the lever in the machine that is most often preferred for the first crushing process in the research laboratories of the mining research industries.
| Model | 48-JC456300 | 48-JC456305 |
|---|---|---|
| Jaw Mouth Dimensions | 100*100 mm | 150 *100 mm |
| Input Size | 100*100 mm. can be fed | 150*100 mm. can be fed |
| Output Grain Size | 0-5 mm (The grain size can be adjusted) | 0-10 mm (The grain size can be adjusted) |
| Body | Reinforced Steel Construction | |
| Jaws | Mn + Cr Alloy Casting Hardened by heat treatment | |
| Capacity | 50-150kg/hour (Depends on the output grain size.) | |
| Noise Emission Level | Max. 85dB | |
| Dimension(W*L*H) | 800*900*970 mm | 800*900*980 mm |
| Weight | 260kg | 280kg |
| Engine Power | 1.5 KW/380V | 2.2KW/380V |
| Product Model | Product Name |
|---|---|
| 48-JC456300 | Laboratory Jaw Crushers, 100 *100 mm - 380 V 50 Hz |
| 48-JC456305 | Laboratory Jaw Crushers, 150 *100 - 380 V 50 Hz |
Standards: ASTM C289
